10V DIGITAL VOLTMETER
Product Code : SCL-MH-11984
The 0-10V Digital Voltmeter is a laboratory-grade diagnostic instrument engineered for precise potential difference measurement in DC circuits. Built for University, Vocational, and Secondary TVET curricula, it ensures high-linearity readings and parallax-free data acquisition. This unit meets ISO 9001:2015 manufacturing protocols, providing the ruggedized stability required for high-frequency institutional use in electromagnetism and circuit analysis modules.
Technical Specifications
|
Tender Specification |
OEM Technical Detail |
|
Measurement Range |
0 - 10V DC |
|
Display Type |
3½ Digit High-Contrast LED/LCD |
|
Housing Material |
Impact-Resistant ABS Polymer / Metal Benchtop Enclosure |
|
Input Impedance |
≥ 10 MΩ (to minimize circuit loading) |
|
Power Supply |
220V/240V AC, 50/60Hz (Internal Transformer) |
|
Connectivity |
4mm Shrouded Safety Terminals |
|
ISO Compliance Code |
ISO 9001:2015; CE Mark |
|
HS Code |
9030.33.00 (Instruments for measuring voltage) |
|
Operating Temperature |
Calibrated for 10°C to 45°C |
Key Pedagogical Outcomes (Bloom’s Taxonomy)
Feature: 3½ Digit Digital Display. Outcome: Eliminates interpolation errors common in analog meters, enabling students to perform precise quantitative verification of Kirchhoff’s Voltage Law.
Feature: High Input Impedance Architecture. Outcome: Demonstrates the principle of "minimal circuit intrusion," allowing advanced students to analyze the loading effects of measuring instruments on high-resistance circuits.
Feature: 4mm Safety Binding Posts. Outcome: Facilitates rapid circuit reconfiguration while ensuring compliance with laboratory safety protocols during Vocational TVET practical examinations.
Feature: Integrated Overload Protection. Outcome: Protects internal circuitry from accidental over-voltage, supporting "Failure Mode Analysis" modules and reducing long-term institutional maintenance costs.
International Logistics & Compliance
This instrument is palletized for international distribution using export-grade seaworthy crating (ISPM-15 compliant). Comprehensive documentation sets are provided to streamline customs clearance, including the Manufacturer’s Authorization Form (MAF), IQ/OQ/PQ Certification, and localized User Manuals in English. The hardware features a tropicalized design, with moisture-sealed PCB assemblies tested for sustained operational integrity in environments reaching 45°C and 90% non-condensing humidity.
Why Source from the OEM?
Direct sourcing from our facility guarantees vertical integration from the component level to final calibration. Unlike generalist traders, we perform in-house PCB population and batch-calibration against NIST-traceable standards to ensure cross-unit uniformity. Procurement through the OEM provides access to direct factory spares availability, firmware support, and the evidentiary quality control required for large-scale government and NGO educational tenders.
