Quick Answer: The Analog Frequency Meter measures AC supply frequency on a pointer scale from 45 Hz to 55 Hz. It works on 230V AC ± 10%, 50Hz, and sits on the bench on an inclined stand.
Last updated: October 2026
Key Features
Measurement range 45 Hz to 55 Hz
Analog pointer with linear scale
Operates on 230V AC ± 10%, 50Hz
4mm shrouded sockets for input
Bench mounting with integrated inclined stand
Technical Specifications
Specification
Value
Measurement range
45 Hz to 55 Hz
Operating voltage
230V AC ± 10%, 50Hz
Display
Analog pointer, linear scale
Input terminals
4mm shrouded sockets
Mounting
Bench, integrated inclined stand
About This Product
The meter lets students watch the mains frequency and see how it shifts slightly as loads change in power and electrical machines practicals. Its narrow range around 50 Hz makes small changes easy to read. Schools, colleges and institutes in Niger, Paraguay, Zimbabwe, Mongolia, Nicaragua and Afghanistan can order the Analog Frequency Meter from Educational Instrument.
