Gold Leaf Electroscope STEM Lab
Product Code : SCL-EI-12543
Quick Answer: The Gold Leaf Electroscope STEM Lab has a solid brass rod carrying ultra-thin gold leaves inside a protective glass chamber, with interchangeable 50mm brass disc and 25mm brass sphere terminals. Replacement gold leaves are included.
Last updated: October 2026
Key Features
- Solid brass conductor rod
- Ultra-thin gold leaves, with replacements included
- Glass chamber with metal frame shields the leaves from air currents
- Interchangeable brass disc (50mm) and brass sphere (25mm) terminals
- Side earthing terminal screw for quick resetting
- Approx. 150mm x 100mm x 200mm, about 450 grams
Technical Specifications
| Specification | Value |
|---|---|
| Conductor | Solid brass rod |
| Leaves | Gold leaf, replacements included |
| Enclosure | Glass chamber with metallic frame |
| Terminals | Brass disc 50mm, brass sphere 25mm |
| Earthing | Side earthing terminal screw |
| Size (L x W x H) | Approx. 150mm x 100mm x 200mm |
| Weight | Approx. 450 grams |
About This Product
Touching a charged glass or ebonite rod to the disc makes the leaves spread apart as like charges repel; bringing the rod close without contact, earthing the disc briefly and then removing the rod leaves the electroscope charged with the opposite sign. Students use it to show charging by friction, conduction and induction, and touching the disc or the earthing screw resets it.
Frequently Asked Questions
How is the Gold Leaf Electroscope STEM Lab discharged?
Touch the brass disc or the earthing terminal with a finger; the charge flows to earth and the leaves hang flat again.
Which terminals are supplied?
A 50mm brass disc and a 25mm brass sphere, which can be swapped on the rod.
Related: Electronic Instruments and Wave Motion Apparatus (24 Pulleys) STEM Lab.
For a quotation on the Gold Leaf Electroscope STEM Lab, contact Educational Instrument.
