Quick Answer: The Hydraulic Brake Model is a working demonstration of a multi-wheel hydraulic brake circuit with a master cylinder and four wheel cylinders. Transparent tubing lets students watch the fluid move as the brakes are applied.
Last updated: October 2026
Key Features
Full-circuit layout: master cylinder and four wheel cylinders
Manual actuation with return spring
Alloy cylinders and brake shoes with friction linings
Transparent reinforced tubing to show fluid flow
Removable components for showing brake shoe wear, cylinder seal failure and system purging
Technical Specifications
Specification
Value
Layout
Master cylinder and four wheel cylinders
Actuation
Manual, with return spring
Cylinders
Alloy
Brake shoes
With friction linings
Fluid lines
Transparent reinforced tubing
About This Product
The model shows Pascal’s law at work: pressure applied at the master cylinder passes through the fluid to all four wheel cylinders. Students can relate input force to output pressure, see how air bubbles affect the circuit and follow the bleeding procedure used on vehicles.
Frequently Asked Questions
How many wheel cylinders does the Hydraulic Brake Model have?
Four wheel cylinders, fed from one master cylinder through transparent tubing, so the spread of pressure across the circuit can be seen.
