Quick Answer: This 80 x 80 mm Analog Panel Meter is a panel-mounting meter for current or voltage, with a moving-coil movement for DC or a moving-iron movement for AC and accuracy class 2.5.
Last updated: October 2026
Key Features
80 mm x 80 mm faceplate
Moving-coil (DC) or moving-iron (AC) movement
Accuracy class 2.5 (±2.5% of full-scale deflection)
ABS housing with acrylic viewing window
Linear scale with anti-parallax pointer and front zero-adjust screw
Technical Specifications
Specification
Value
Faceplate
80 mm x 80 mm
Movement
Permanent magnet moving coil (DC); moving iron (AC)
Accuracy class
2.5 (±2.5% FSD)
Housing
ABS, acrylic window
Scale
Linear, anti-parallax pointer
Zero adjustment
Front-mounted screw
About This Product
Panel meters of this size are fitted to trainer boards, distribution panels and experiment benches so a whole group can read current or voltage from a distance. They suit electrical and electronics labs where a circuit needs a permanent meter rather than a handheld one.
Frequently Asked Questions
What accuracy does the 80 x 80 mm Analog Panel Meter have?
It is accuracy class 2.5, that is ±2.5% of full-scale deflection.
