Solar Energy Kit with Lamp STEM Lab
Product Code : SCL-EI-12556
Quick Answer: The Solar Energy Kit with Lamp pairs a 3.0 W monocrystalline solar panel with a 50W halogen lamp on a gooseneck arm, so solar experiments can run indoors in any weather. Built-in meters, a supercapacitor and a choice of loads show how the panel performs.
Last updated: October 2026
Key Features
- Monocrystalline silicon panel, 3.0 W peak, in a tempered glass and aluminium frame
- Angle-adjustable panel mount with tilt markings
- 50W halogen lamp on an adjustable gooseneck arm as a simulated sun
- On-board DC voltmeter and ammeter
- Loads: variable potentiometer, DC motor with fan blade, piezo buzzer and 2 LED array
- Supercapacitor with isolation switch; ABS console with printed wiring diagram
Technical Specifications
| Specification | Value |
|---|---|
| Solar panel | Monocrystalline silicon, tempered glass, aluminium frame |
| Peak power | 3.0 W |
| Light source | 50W halogen lamp, gooseneck arm |
| Meters | DC voltmeter, DC ammeter |
| Loads | Potentiometer, DC motor with fan, piezo buzzer, 2 LEDs |
| Energy storage | Supercapacitor with isolation toggle switch |
| Console base | 320 mm x 240 mm x 85 mm; about 450 mm high with lamp extended |
About This Product
Moving the lamp or tilting the panel and reading the meters lets students see how output falls as light strikes at a wider angle or from further away, illustrating the cosine law and the inverse-square law. Switching between the motor, buzzer, LEDs and potentiometer shows how the panel behaves under different loads, so they can plot voltage-current curves and estimate efficiency, while the supercapacitor shows energy being stored. Laboratories and colleges in Chile, Trinidad and Tobago, Bhutan, Chad, Malawi and Jamaica can buy the Solar Energy Kit with Lamp STEM Lab through an export order.
Frequently Asked Questions
Can the Solar Energy Kit be used without sunlight?
Yes. The 50W halogen lamp on the gooseneck arm acts as a steady artificial sun for indoor experiments.
What loads can the panel drive?
A DC motor with fan blade, a piezo buzzer, a 2 LED array and a variable potentiometer.
Related: Electronic Instruments and Stem Lab Kit STEM Lab.
For a quotation on the Solar Energy Kit with Lamp STEM Lab, contact Educational Instrument.
