Pyrometer, Superior Pattern
Product Code : SCL-MH-11977
Engineered for the non-contact quantification of extreme thermal energy, this Superior Pattern Pyrometer utilizes total radiation detection to eliminate emissivity-related errors. It facilitates the empirical validation of the Stefan-Boltzmann Law and Planck’s Law within University and Vocational Research curricula. Designed for high-fidelity alignment with ASTM E633 standards, it enables precise temperature monitoring of industrial furnaces and black-body sources.
Technical Specifications
|
Tender Specification |
OEM Technical Detail |
|
Optical Configuration |
Superior Pattern Concave Reflector with Gold-Plated Surface |
|
Detection Element |
Rapid-Response Multi-Junction Thermopile |
|
Housing Construction |
Cast Aluminum / Heavy-Duty Brass with Heat-Dissipating External Finishes |
|
Focusing Mechanism |
Rack and Pinion Precision Adjustment for Focal Point Convergence |
|
Aperture Control |
Calibrated Diaphragm for Radiation Flux Attenuation |
|
Mounting Interface |
Integrated 1/4" Thread for Tripod or Laboratory Optical Bench |
|
ISO Compliance Code |
ISO 9001:2015 / CE Marked for Laboratory Safety |
|
HS Code |
9025.19 (Instruments for temperature measurement) |
Key Pedagogical Outcomes (Bloom’s Taxonomy)
Feature: Rack and Pinion Focusing System. Outcome: Allows students to master optical convergence and focal length calculations in accordance with Geometric Optics principles.
Feature: Gold-Plated Concave Reflector. Outcome: Students observe high-reflectivity efficiency and minimize absorption loss, supporting advanced study of the Inverse Square Law.
Feature: Integrated Multi-Junction Thermopile. -Outcome: Enables the conversion of radiant flux into millivolt output, facilitating quantitative data analysis for Thermodynamics Module 501.
Feature: Internal Absorption Filters. -Outcome: Provides empirical data on wave-length attenuation, supporting learning objectives related to Kirchhoff’s Law of Thermal Radiation.
International Logistics & Compliance
This instrument is configured for global B2B procurement and tender fulfillment. Units are secured in export-grade seaworthy crating (ISPM-15 compliant) to protect delicate optical coatings and precision mechanical focusing assemblies. Documentation provided with each consignment includes the Manufacturer’s Authorization Form (MAF), IQ/OQ/PQ certification, and comprehensive technical manuals in English. The tropicalized design ensures performance stability in laboratory environments up to 45°C and 90% humidity, preventing oxidation of the detection elements.
Why Source from the OEM?
Direct procurement ensures vertical integration, from the in-house optical grinding and surfacing of the concave reflectors to the precision assembly of the thermopile detection units. Unlike generalist traders, our "Superior Pattern" units undergo batch-testing for uniformity against calibrated NIST-traceable black-body radiators. Sourcing from the OEM guarantees direct factory spares availability, providing critical long-term maintenance support for institutional laboratory assets.
