Lamps in Series Kit STEM Lab
Product Code : SCL-EI-12574
Quick Answer: The Lamps in Series Kit is a circuit panel with 3 lamp sockets wired one after another and an inline toggle switch, for showing how current behaves in a single-path circuit. It runs on 3V to 6V DC and comes with 5 MES lamps and 6 banana patch cables.
Last updated: October 2026
Key Features
- 3 lamp sockets in a sequential series layout with inline toggle
- Circuit schematic printed on the ABS panel
- 4mm insulated brass banana jacks
- Meter connection points beside each component for ammeters and voltmeters
- Supplied with 5 low-voltage MES lamps, 6 insulated patch cables and an instructor’s guide
Technical Specifications
| Specification | Value |
|---|---|
| Configuration | 3 sockets in series with inline toggle |
| Panel | ABS polymer with printed schematic |
| Terminals | 4mm insulated brass banana jacks |
| Operating voltage | 3V to 6V DC |
| Package contents | 1 panel, 5 MES lamps, 6 banana patch cables, 1 lab guide |
About This Product
With the lamps fitted and the chain completed with patch cables, switching on the DC supply lights every lamp, but each is dimmer than a single lamp alone because the voltage is shared. Unscrewing one lamp puts them all out, showing that a series circuit has only one path. Meters connected at the ports let students measure the current and the voltage across each lamp, linking the result to old-style string lights and fuses. Enquiries from Namibia, Turkmenistan, Colombia, Rwanda, Vietnam and Brunei for the Lamps in Series Kit STEM Lab receive an export quotation.
Frequently Asked Questions
Why do all the lamps go out when one is removed?
In a series circuit the current has only one path. Removing any lamp breaks that path, so no current flows to the others.
Why are the lamps dimmer in series?
The supply voltage is shared between the lamps, so each one receives only part of it.
Related: Electronic Instruments and Lamps in Parallel Kit STEM Lab.
For a quotation on the Lamps in Series Kit STEM Lab, contact Educational Instrument.
