Step Down Transformer
.png)
Product Code : SCL-EI-12118
Engineered specifically for determining AC mains frequency via sonometer resonance experiments, this instrument provides a regulated 6V AC output to drive laboratory electromagnets. Built to ISO 9001:2015 standards, it supports University and Higher Secondary physics curricula by providing consistent electromagnetic induction. The unit eliminates experimental variance caused by voltage fluctuations in institutional electrical grids, ensuring repeatable harmonic analysis.
Technical Specifications
|
Tender Specification |
OEM Technical Detail |
|
Input Voltage |
220V - 240V AC, 50Hz |
|
Output Potential |
6V AC (Fixed) |
|
Current Rating |
2 Amperes (Continuous Duty) |
|
Core Construction |
High-permeability laminated silicon steel core |
|
Winding Material |
Double-insulated, vacuum-impregnated copper windings |
|
Material Grade |
Ruggedized, ventilated metal chassis (Powder-Coated) |
|
Interface |
4mm Shrouded safety sockets (Color-coded) |
|
Safety Features |
Primary side glass fuse protection |
|
ISO Compliance Code |
ISO 9001:2015 / CE Certified |
|
HS Code |
8504.31.00 (Transformers, capacity < 1kVA) |
Key Pedagogical Outcomes (Bloom’s Taxonomy)
Feature: Constant 6V AC Output. Outcome: Facilitates the precise determination of the frequency of alternating current by achieving resonance in stretched wires, supporting the "Analysis" level of cognitive development.
Feature: High-Stability Electromagnetic Flux. Outcome: Allows students to "Evaluate" the relationship between tension, mass per unit length, and vibrating length without thermal interference in the electromagnet.
Feature: Galvanically Isolated Secondary Winding. Outcome: Ensures institutional safety by decoupling experimental setups from mains potential, allowing students to "Apply" theoretical physics principles in a secure environment.
Feature: Ruggedized Metal Housing. Outcome: Provides durability for high-frequency usage in vocational settings, supporting long-term "Synthesis" of wave mechanics and electromagnetism modules.
International Logistics & Compliance
To ensure global tender compliance, all units are dispatched in export-grade seaworthy crating (ISPM-15 compliant) featuring internal moisture barriers. Documentation packages include the Manufacturer’s Authorization Form (MAF), IQ/OQ/PQ Certification (Installation, Operational, and Performance Qualification), and comprehensive User Manuals in English. The instrument utilizes a tropicalized design, rigorously tested for sustained operation in environments reaching up to 45°C and 90% non-condensing humidity, making it ideal for institutional procurement in the MENA and APAC regions.
Why Source from the OEM
Procuring directly from the OEM guarantees vertical integration of the manufacturing process, including in-house precision winding of copper coils and magnetic flux testing. Unlike secondary traders, we provide batch-tested uniformity across all shipments and ensure direct factory spares availability for institutional maintenance. Our forensic quality control process ensures that every transformer maintains calibrated output tolerances, which is a critical requirement for generating reliable scientific data in educational environments.
