Ticker Tape Timer
Product Code : SCL-MH-11945
The Ticker Tape Timer is a precision electromechanical instrument engineered for quantitative kinematic analysis in secondary and vocational physics curricula. Utilizing a fixed-frequency electromagnetic vibrator, it records discrete temporal data points on pressure-sensitive or carbon-interleaved media. It is compliant with international educational laboratory safety standards for low-voltage AC operation, facilitating the empirical derivation of velocity and acceleration.
Technical Specifications
|
Tender Specification |
OEM Technical Detail |
|
Operating Voltage |
6V - 12V AC (Frequency Dependent) |
|
Marking Frequency |
50 Hz / 60 Hz (Synchronized to Mains) |
|
Timing Interval |
0.02s (at 50Hz) or 0.0167s (at 60Hz) |
|
Chassis Material |
Impact-Resistant ABS or Die-Cast Alloy on Heavy Bakelite Base |
|
Recording Media |
15mm-17mm width Ticker Tape; 40mm-50mm Carbon Discs |
|
Electromagnetic Actuator |
Solenoid with Spring-Loaded Steel Vibrator Arm |
|
ISO Compliance |
ISO 9001:2015 / ISO 17025 (Reference Standards) |
|
HS Code |
9023.00.10 (Educational/Instructional Apparatus) |
Key Pedagogical Outcomes (Bloom’s Taxonomy)
Feature: Fixed-Frequency Electromagnetic Solenoid. - Outcome: Enables students to Apply the relationship between frequency and period to establish a constant time base for motion intervals.
Feature: Integrated Tape Guide and Carbon Disc Peg. -Outcome: Facilitates the Analysis of displacement-time data by ensuring high-contrast, non-smearing physical records of non-uniform motion.
Feature: Synchronous Marking Arm. Outcome: Allows learners to Evaluate experimental errors and frictional coefficients by comparing theoretical free-fall acceleration ($g$) with empirical tape data.
Feature: Modular Base Mounting Sockets. Outcome: Supports the Creation of complex dynamics experiments involving inclined planes, trolleys, and pulley systems.
International Logistics & Compliance
Our global supply chain is optimized for high-volume institutional tenders. All units are secured in export-grade seaworthy crating (ISPM-15 compliant) to ensure structural integrity during maritime or aerial transit. Documentation packages provided with each consignment include Manufacturer’s Authorization Forms (MAF), Certificate of Origin (COO), and comprehensive Technical Manuals in English. The instrument features a tropicalized design, stress-tested for prolonged operation in ambient temperatures up to 45°C and 90% non-condensing humidity, ensuring reliability in diverse geographical laboratory environments.
Why Source from the OEM?
As an established Manufacturing Export House with over 75 years of vertical integration, we maintain total control over the production lifecycle. Unlike third-party traders, our facility handles in-house metal fabrication, coil winding, and assembly, ensuring batch-to-batch uniformity and strict adherence to calibration tolerances. This direct-factory model guarantees the long-term availability of genuine spares (carbon discs, precision springs, and tapes) and provides procurement officers with a transparent, verifiable audit trail for quality assurance.
